Installation and Commissioning Index

Overview & Commissioning Process

Virtual Commissioning and Testing — What “commissioned” means for BluSKY systems and how to prove a system is assembled, wired, configured, and ready. Includes the intent of commissioning tests and an outline of what to verify before hand‑off.
BluINFO Link. (BluINFO)

Differentiators: Virtual Remote Commissioning & Power Management — Highlights BluB0X’s ability to configure, test, and diagnose systems remotely, with remote power control, battery checks, and system health history to speed installation and service.
BluINFO Link. (BluINFO)

Professional Services (Install & Commissioning Support) — When you need BluB0X help onsite or remotely: installation services, commissioning support, technical training, API work, and more.
BluINFO Link. (BluINFO)

Two‑Door Demo (Hands‑On Build & Wire) — A guided exercise showing how to assemble and configure a simple LP1502 system with readers, REX, DPS, wiring, and BluSKY connectivity—useful as a mini‑commissioning dry run.
BluINFO Link. (BluINFO)

Controllers & SIO Hardware Setup

Controller Hardware Configuration (Mercury) — Field steps and concepts for addressing boards (DIP switches), setting baud rates, and preparing controllers and modules for service. BluINFO Link. (BluINFO)

Network Configuration for Controllers (First Login & Defaults) — How to put a controller on your bench network, use factory defaults (192.168.0.251; admin/password), set DIP 1/2 correctly, then assign proper IP/gateway/DNS for the site. BluINFO Link. (BluINFO)

Connect a Controller to BluSKY (Host Settings & Ports) — Exact host/port/TLS settings (e.g., TLS Required, host blub0x.cloudapp.net, ports 3010–3017) and a reminder to allow the port in local firewalls during commissioning. BluINFO Link. (BluINFO)

Connecting an MR51e — Uses Mercury’s MR51e Address Tool to assign static IPs and bring MR51e boards online with EP/LP controllers; includes DIP and firewall notes. BluINFO Link. (BluINFO)

BluSKY Connect (Controller conversion & bulk erase) — Utility and procedure to reset Mercury boards, erase memory, and move between OEM images when re‑deploying hardware for BluSKY.
BluINFO Link. (BluINFO)

Avoiding TLS Errors on Older EP Controllers — Temporary Firefox settings to reach legacy EP web UIs when modern browser TLS blocks access during bench setup. BluINFO Link. (BluINFO)

Upgrade Mercury Firmware (direct‑connected PC) — When no site network is available, update controller firmware via a direct connection; includes file examples and reboot behavior. BluINFO Link. (BluINFO)

Replace/Upgrade a Mercury Controller (EP/LP/MP) — One‑for‑one board replacement steps, controller type changes in BluSKY, and the correct order to clear/sync controllers and people. BluINFO Link. (BluINFO)

Power, Enclosures & Wiring Best Practices

Wire Lengths & Gauge Best Practices — Quick reference for 12VDC/24VAC runs so locks and devices get full power without voltage drop surprises during commissioning.
BluINFO Link. (BluINFO)

LifeSafety Power — Component Interconnect & Variants — How NL4, M8/M8P, and enclosure options fit together; patterns for adding remote management or scaling to 8‑door kits.
BluINFO Link. (BluINFO)

RB8 Wiring (Controller Power Disconnect) — Replacing RB2 with RB8 for NL4‑driven power control of Mercury boards; explains why RB8 needs unswitched power plus the NL4 trigger.
BluINFO Link. (BluINFO)

NL4 Network Link (LSP) Datasheet — Adds network power monitoring/management (battery, outputs, faults) to enclosures for remote diagnosis and commissioning checks.
BluINFO Link. (BluINFO)

M8 / M8P Lock Power Controllers — Eight monitored/controlled outputs via NL4—commissioners can switch, monitor, and protect lock power from BluSKY. BluINFO Link. (BluINFO)

BluCHIP Access Control Kits (selected examples) — Pre‑built, unified kits (enclosure + power + Mercury + managed lock power) that reduce onsite wiring time and simplify commissioning:

1502‑2R/8I/4O‑E2MLPM — two‑reader base, expandable to four. Link. (BluINFO)

2500‑2R/8I/4O‑E4M1LPM — scalable platform with remote power diagnostics. Link. (BluINFO)

1502‑4R/16I/10O‑E2M1LPM — four‑reader kit with managed lock power. Link. (BluINFO)

Person Reader — Physical Installation & Wiring

How to Mount a Person Reader — Practical mounting rules (height, plane, sightlines, lighting), turnstile notes, and how to avoid IR projector interference—so recognition works on day one. BluINFO Link. (BluINFO)

Person Reader Cable Connections — Exact USB/HDMI/Ethernet/audio connections between the sensor head and the NUC; color‑ringed cable callouts and back‑view mapping. BluINFO Link. (BluINFO)

Physical Installation of the Person Reader — Where to place the sensor head (unsecured side), cable types (USB/HDMI/Audio), 6′ USB run guidance, and how Ethernet/power route to ACP/switches. BluINFO Link. (BluINFO)

Person Reader Mounting Guidelines (Quick Rules) — Keep the center camera ~52″–60″ AFF (50″ ADA), mount on handle side, keep in the door plane, avoid spotlights; designed to preserve normal user approach behavior. BluINFO Link. (BluINFO)

Person Reader Gen 3 — Pinouts & Wiring — PDF diagrams for PR V3/L3 and the AIC‑2 base, with terminal callouts used during rough‑in and punch‑list verification. BluINFO Link. (BluINFO)

OSDP Reader Wiring & Enablement — Four‑wire OSDP wiring, HID reader settings, and BluSKY configuration—all you need to move from Wiegand to secure OSDP during commissioning. BluINFO Link. (BluINFO)

Wiegand Converter — Program IP & Wiring — How to set the Wiegand converter’s IP/MAC and basic Arduino‑based wiring notes (including tying grounds when power sources differ). BluINFO Link • Wiring Arduino. (BluINFO)

BluPOINT Nano — Mounting & Antenna Orientation — Turnstile placement (offsets, 25° yaw) and antenna orientation maps to get reliable mobile credential performance in tight spaces. BluINFO Link. (BluINFO)

BluPOINT Nano Reader (Datasheet) — Ultra‑small module for embedded installs (elevators, turnstiles, copiers) that drops in quickly where power and controller cabling exist. BluINFO Link. (BluINFO)

Network & VLAN Patterns / Connectivity

BluSKY VPN & Network Monitoring — A subscription feature that gives secure, click‑through remote access to onsite devices without punching firewall holes; required for VMS integrations, Destination Dispatch Elevators, and Person Readers. Ideal for commissioning and ongoing support. BluINFO Link. (BluINFO)

Information Security (IT Talking Points) — How BluB0X applies network and application security best practices (data center, comms, browser/mobile security, cryptography) and IP networking considerations—useful when designing VLANs and firewall policy. BluINFO Link. (BluINFO)

VMS A&E Spec — NAT & Traversal — Requirements and guidance for VMS networks, including enabling client access to recording servers from outside NAT firewalls (port forwarding), helpful during multi‑site commissioning. BluINFO Link. (BluINFO)

Video – New System (Design Considerations) — Calls out the need for Layer‑3 switching on the camera network and other infrastructure pointers that affect commissioning stability and performance. BluINFO Link. (BluINFO)

BluSKY Overview — Network Requirement — Core protocol requirements for BluSKY access (HTTPS/443), useful in IT pre‑checks and firewall reviews.
BluINFO Link. (BluINFO)

Controller → BluSKY Host (Firewall Reminder) — When pointing controllers to BluSKY, ensure the selected controller port (typically 3010–3017) is allowed through local firewalls; TLS setting must match BluSKY. BluINFO Link. (BluINFO)

Elevator, Turnstile & DDE Install Profiles

Destination Dispatch Person Reader (Models & Fit‑Out) — PR sizes for DDE terminals/turnstiles, UI basics, and how integrated elevator assignment reduces ghost calls and improves throughput. BluINFO Link. (BluINFO)

TKE Destination Dispatch Person Readers (Variants) — PR options packaged for TK Elevator deployments (lobby, turnstile, upper‑floor panels) to streamline modernization projects. BluINFO Link. (BluINFO)

In‑Car Person Reader (Install Options & Networking) — Surface‑mount or behind‑panel installs; networking over traveler cable via Ethernet‑to‑twisted‑pair converters reduces install complexity; supports EMS analytics. BluINFO Link. (BluINFO)

DDE “Typicals” (Bill‑of‑Materials & Notes) — Multi‑car kits and integrated systems showing hardware blocks and a note that installation & commissioning require BluB0X Professional Services. 8‑Car DDE Readers→DDE • 8‑Car DDE Readers→Security • Integrated Systems Typical. (BluINFO)

Performance Baselines, Verification & Tuning

Destination Dispatch Elevator Basics (Recommended Performance Values) — Baseline KPI table for DDE (e.g., response/wait targets) to validate performance during commissioning and acceptance. BluINFO Link. (BluINFO)

SimEYES — Elevator Simulation & Analysis — Model traffic and test strategies before hardware is ready; validate observed operations against simulated KPI baselines post‑install to catch drift. BluINFO Link. (BluINFO)

SimEYES (Blog: Benchmarking & Digital‑Twin KPIs) — Explains continuous comparison of KPI baselines vs. live telemetry and using reinforcement learning simulations to quantify gains. BluINFO Link. (BluINFO)

Milestone VMS Configuration Best Practices — Video stream defaults (resolution, frame rate, bitrate, GOP, H.264 profile) that serve as a commissioning baseline for reliable live/recorded video. BluINFO Link. (BluINFO)

LVSM Snapshot (Release Note) — Adds snapshot capability for Avigilon/Exacq NVRs to aid incident verification and performance checks in the field.
BluINFO Link. (BluINFO)

EMS (Elevator Management System) — Outcomes to Validate — What to measure post‑commissioning (e.g., reduced ghost calls, efficiency lift) when PRs and EMS are integrated. BluINFO Link. (BluINFO)

Appendix: Quick IT Talking Points for Commissioning

Use HTTPS/443 for BluSKY and ensure controller ports (typically 3010–3017) are allowed outbound; enforce the TLS mode selected in BluSKY. Details • Host/Port. (BluINFO)

Prefer Layer‑3 switching on the video network; plan NAT/port‑forwarding if remote VMS access is required. Details • VMS A&E Spec. (BluINFO)

For secure remote commissioning/support without opening inbound firewall rules, enable the BluSKY VPN / Remote Management Gateway (required for PR, DDE, and VMS integrations). Details. (BluINFO)

When commissioning elevator VVT/PR endpoints, follow the implementation blueprint (SIP/VoIP on building IT, VLAN segmentation, unified EMS) to avoid siloed OEM networks. White Paper. (BluINFO)
