HID Mobile Access Ordering Information

Mobile Enabled Readers:

Readers that come with the MOB key pre-loaded from the HID Factory.

ICLASS SE 2.4 GHz and 13.56 MHz only – Red LED
900NMNNEKEA001 - R10 (Mini-Mullion) with Pigtail
910NMNNEKEA001 - R15 (Mullion) with Pigtail
920NMNNEKEA001 - R40 (Wallswitch) with Pigtail
921NMNNEKEA002 - RK40 (Wallswitch Keypad) with Pigtail
900NMNTEKEA001 - R10 (Mini-Mullion) with Terminal Strip
910NMNTEKEA001 - R15 (Mullion) with Terminal Strip
920NMNTEKEA001 - R40 (Wallswitch) with Terminal Strip
921NMNTEKEA002 - RK40 (Wallswitch Keypad) with Terminal Strip

multiCLASS SE 2.4 GHz, 13.56 MHz & 125 kHz – Red LED
900PMNNEKEA003 - RP10 (Mini-Mullion) with Pigtail
910PMNNEKEA003 - RP15 (Mullion) with Pigtail
920PMNNEKEA003 - RP40 (Wallswitch) with Pigtail
921PMNNEKEA004 - RPK40 (Wallswitch Keypad) with Pigtail
900PMNTEKEA003 - RP10 (Mini-Mullion) with Terminal Strip
910PMNTEKEA003 - RP15 (Mullion) with Terminal Strip
920PMNTEKEA003 - RP40 (Wallswitch) with Terminal Strip
921PMNTEKEA004 - RPK40 (Wallswitch Keypad) with Terminal Strip

iCLASS SE 2.4 GHz and 13.56 MHz only – Blue LED
900NMNNEKEA0CH - R10 (Mini-Mullion) with Pigtail
910NMNNEKEA0CH - R15 (Mullion) with Pigtail
920NMNNEKEA0CH - R40 (Wallswitch) with Pigtail
921NMNNEKEA0CJ - RK40 (Wallswitch Keypad) with Pigtail
900NMNTEKEA0CH - R10 (Mini-Mullion) with Terminal Strip
910NMNTEKEA0CH - R15 (Mullion) with Terminal Strip
920NMNTEKEA0CH - R40 (Wallswitch) with Terminal Strip
921NMNTEKEA0CJ - RK40 (Wallswitch Keypad) with Terminal Strip

multiCLASS SE 2.4 GHz, 13.56 MHz & 125 kHz – Blue LED
900PMNNEKEA0CG - RP10 (Mini-Mullion) with Pigtail
910PMNNEKEA0CG - RP15 (Mullion) with Pigtail
920PMNNEKEA0CG - RP40 (Wallswitch) with Pigtail
921PMNNEKEA0CK - RPK40 (Wallswitch Keypad) with Pigtail
900PMNTEKEA0CG - RP10 (Mini-Mullion) with Terminal Strip
910PMNTEKEA0CG - RP15 (Mullion) with Terminal Strip
920PMNTEKEA0CG - RP40 (Wallswitch) with Terminal Strip
921PMNTEKEA0CK - RPK40 (Wallswitch Keypad) with Terminal Strip

Mobile Ready Readers:

Reader includes Bluetooth Module & firmware / assemblies. (MOB keys are not loaded at the factory) MOB keys will need to be loaded in the field.

iCLASS SE - 2.4 GHz and 13.56 MHz only – Red LED
900NMNNEKMA001 - R10 (Mini-Mullion) with Pigtail
910NMNNEKMA001 - R15 (Mullion) with Pigtail
920NMNNEKMA001 - R40 (Wallswitch) with Pigtail
921NMNNEKMA002 - RK40 (Wallswitch Keypad) with Pigtail
900NMNTEKMA001 - R10 (Mini-Mullion) with Terminal Strip
910NMNTEKMA001 - R15 (Mullion) with Terminal Strip
920NMNTEKMA001 - R40 (Wallswitch) with Terminal Strip
921NMNTEKMA002 - RK40 (Wallswitch Keypad) with Terminal Strip

multiCLASS SE 2.4 GHz, 13.56 MHz & 125 kHz – Red LED
900PMNNEKMA003 - RP10 (Mini-Mullion) with Pigtail,
910PMNNEKMA003 - RP15 (Mullion) with Pigtail
920PMNNEKMA003 - RP40 (Wallswitch) with Pigtail
921PMNNEKMA004 - RPK40 (Wallswitch Keypad) with Pigtail
900PMNTEKMA003 - RP10 (Mini-Mullion) with Terminal Strip
910PMNTEKMA003 - RP15 (Mullion) with Terminal Strip
920PMNTEKMA003 - RP40 (Wallswitch) with Terminal Strip
921PMNTEKMA004 - RPK40 (Wallswitch Keypad) with Terminal Strip

iCLASS SE - 2.4 GHz and 13.56 MHz only – Blue LED
900NMNNEKMA0CH - R10 (Mini-Mullion) with Pigtail
910NMNNEKMA0CH - R15 (Mullion) with Pigtail
920NMNNEKMA0CH - R40 (Wallswitch) with Pigtail
921NMNNEKMA0CJ - RK40 (Wallswitch Keypad) with Pigtail
910NMNTEKMA0CH - R10 (Mini-Mullion) with Terminal Strip
900NMNTEKMA0CH - R15 (Mullion) with Terminal Strip
920NMNTEKMA0CH - R40 (Wallswitch) with Terminal Strip
921NMNTEKMA0CJ - RK40 (Wallswitch Keypad) with Terminal Strip

multiCLASS SE 2.4 GHz, 13.56 MHz & 125 kHz – Blue LED
900PMNNEKMA0CG - RP10 (Mini-Mullion) with Pigtail,
910PMNNEKMA0CG - RP15 (Mullion) with Pigtail
920PMNNEKMA0CG - RP40 (Wallswitch) with Pigtail
921PMNNEKMA0CK- RPK40 (Wallswitch Keypad) with Pigtail
900PMNTEKMA0CG - RP10 (Mini-Mullion) with Terminal Strip
920PMNTEKMA0CG - RP40 (Wallswitch) with Terminal Strip
921PMNTEKMA0CK - RPK40 (Wallswitch Keypad) with Terminal Strip

New Mobile Credential Part Numbers:

Mobile-ID: (Minimum Order is 100)

• Must Provide Org # or Company Name, MOB Key, Format, Facility Code and Number Range
• If Corp 1000 customer only provide Org # or Company Name, Format, and MOB KEY

Mobile-ID-TEMP7: (7 Day Self Expiring) (Minimum Order 500)

• Must Provide Org # or Company Name, MOB Key, Format, Facility Code and Number Range
• If Corp 1000 customer only provide Org # or Company Name, Format, and MOB KEY

SEC9X-CRD-MADD: (Mobile Admin Card)

• Admin card to change read range settings in the reader
• Used with the BLE Configuration App
• Must Provide Org # or Company Name and MOB Key
• Min Order Qty – 1

SEC9X-CRD-E-MKYD (Mobile Key Card)

• Configuration Card used to load a MOB key on to a reader in the field
• Must be ordered with a MOB key referenced
• Min Order Qty – 1

Training

Mobile Access Video: https://www.youtube.com/watch?v=ztkngP5jfjI&feature=youtu.be

HID Training Academy:

It’s recommended and highly encouraged that the below mobile sales & technical training modules are taken on the HID Training Academy prior to selling or installing this solution https://hidglobal.csod.com/client/hi...l/default.aspx

Mobile Modules:

• HID Mobile Access® Sales Training
• HID Mobile Access Administration Portal Technical Training v1
• iCLASS SE Mobile Access Reader Technical Training
• HID Mobile Access: How to Configure Readers Using the HID Mobile Access BLE Configuration App

PLEASE NOTE! Specifications contained herein are subject to change without notice. HID is not responsible for any typographical errors.
