Overview

The FPO family of switch mode power supplies incorporates the advanced FlexPower feature set, two user outputs, 12V or 24VDC user selectability, Fire Alarm Interface function, on board programmable battery charger, fault detection reporting, and network monitoring and programming capability of battery, power, and fault status.

Features

Listed for Fire Alarm, Intrusion, Access Control, CCTV and Mass Notification
DC1 and DC2 output - DC2 switched output programmable for fail-safe or fail secure operation via the FAI/Access control input
Flexible FAI/Access control input with optional latching feature for Canadian installations
Full fault detection, including earth ground detection and battery presence detection
Datalink connection provides accurate data log of battery usage for proper replacement service
Network interface for remote monitoring with optional NetLink module
Accepts a 120 or 230 VAC nominal input at 50 Hz or 60Hz

Products

LifeSafety Power FP0250
The FPO250 is an offline switchmode power supply-battery charger specifically designed for the lifesafety industry capable of providing two outputs, user selectable for 12 or 24VDC
LifeSafety Power FPO150
The FPO150 is an offline switchmode power supply-battery charger specifically designed for the lifesafety industry capable of providing two outputs, user selectable for 12 or 24VDC.
LifeSafety Power FPO75
LifeSafety Power FPO75 is a patented power management system for security and life safety applications. Complete fault detection and reporting, with programmable fault delays, is provided along with datalogging capability of fault occurrence, battery usage time and current power supply status.

The different models at a glance

Model	Output Voltage and Amperage	Total Wattage	Charging Rate
FPO75	6A/ 12V or 3A/ 24V	75W	40Ah
FPO150	12A/ 12V or 6A/ 24V	150W	80Ah
FPO250	20A/ 12V or 10A/ 24V	250W	80Ah
